Technical
specifications

SHEET

Type DX51D+Z cold rolled structural steel (UNI EN 10326)
Galvanization by hot dip - Sendzimir system (UNI-EN 10147)
Pre-lacquered exterior in polyester with 25µ
Interior primer coat with 10µ
Thickness of upper sheet: 0.4mm - 0.5mm - 0.6mm - 0.7mm - 0.8mm
Thickness of lower sheet: 0.4mm - 0.5mm
(Other finishes, thicknesses and sheet types available on request)

PROTECTION OF PRE-LACQUERED SHEETS

Adhesive PVC protection film on the external side of the panels (Standard)
Adhesive PVC protection film on the internal side of the panels (On request)
Adhesive PVC protection film on the external side of the streamlines sheets (On request)

PROTECTION OF PRE-LACQUERED SHEETS

Density: 40 Kg/m3 (±10%)
Thermal conductivity: λ= 0,020 W/mk
Closed cell content: ›92%
Water absorption: ‹1%

INSULATION IN STONE WOOL

Density: 100 Kg/m3 (±10%)
Thermal conductivity: λ = 0,032 W/mk

 NOTE: For information  about resistance to traction, compression, adherence, etc. ask for the certificate of each product.

— COMPARATIVE THERMAL INSULATION DATA —

?
